Partnertech SP635 – E1 POS Touch Terminal PC (1Y)

POS

On backorder

Additional information

Manufacturer	PARTNERTECH
Item Category	POS Terminals

Specification
Item	SP-635-E
Size	15″
Aspect Ratio	4:03
Resolution	1024 x 768
Brightness	350 nits
Touch	PCAP Touch
CPU	Intel® Celeron® J6412 (Elkhart Lake)
Memory	DDR4 4GB,
Storage	2.5″ SATA SSD 256G
I/O Interface	4 x serial ports, RS232 (DB9), 0V/5V/12V selected in BIOS (COM1 , COM2, COM3, COM4)
	1 x LAN (IEEE 802.3 10/100/1000 Mbps)
	1 x RJ11 port support for 2 cash drawers with 24V / 12V jumper setting
	1 x DC +12V out
	4 x USB 3.2
	1 x DC +12V input
	1 x audio (1 x line-out) + mic in
	1 x VGA
Speaker	1 x speaker (3W)
Peripheral Options	MSR, IC Card reader, fingerprint reader, RFID/ NFC, i-Button, V FD, USB 2nd display,
Peripheral Options	VGA/HDMI 2nd display
Wireless Option	Wi-Fi 6E Intel AX210
Wireless Option	IEEE 802.11 a/b/g/n/acR2/axR2, BT 5.2
Display Support	2 independent displays (Main Display + VGA)
Spill & Dust Resistant	IP54 Certified
Operating System	1. Windows 11 IoT Enterprise GAC (64bit) ready
	2. Windows 10 IoT Enterprise LTSC 21H2 (64bit)
	3. Linux Ubuntu 22.04
TPM	S/W TPM 2.0 (BIOS)
Power Adaptor	AC-In 100~240V / DC-Out 12V, 65W / 90W
Reliability	System operating temperature: 0~40°C / 32~104°F
	System humidity: 15% ~ 80%
	Storage temperature: -20~60°C / -4~140°F
Dimensions (Wx Hx D)	360 x 365 x 240 mm / 14.17 x 14.37 x 9.45 in
Weight	9 kg / 19.84 lb
